Save yourself countless hours of time and wire your bike like we do ours! The ultimate diagram to wire the Mo.Unit blue to your BMW K1100RS. This is the most compact wiring diagram available, fully tested and approved! Now available as V3 with extensive schematics on how to wire the K-box.

Works for all K100 16V and K1100's. And will save you hours of fiddling with the most complicated aspect of these builds.

UPDATED VERSION 28/01/2025
